X5036 vertical milling head
Manual knee type machine, vertical milling head, rigidity structure
| Categories | Manual Milling Machine |
|---|---|
| Brand | ZOPO INTELLIGENT EQUIPMENT MACHINING CENTER OEM |
| Model | X5036 |
| BRAND | ZOPO CNC |
| CONTROL | MANUAL |
| SPINDLE | vertical milling head |
| Update Time | Nov 24,2024 |
Detail Information
X5036
KNEE TYPE MILLING MACHINE
1020/300/410mm
X/Y/Z axis travel
360×1600mm
Worktable size
1500rpm
Spindle speed
2250/2250/844mm/min
Rapid feed speed
- Model
- Appearance
- Characteristics
- Parameters
- Contact Us
Appearance
Characteristics
Rigidity structure +Stability precision
This vertical knee type milling machine has high rigidity structure and stable precision.Three direction of guideways have adopted wear-resistant measuresment to maintain high accuracy and long life.
Extensive Application
Mounted with rod, disc, angle, forming and face milling cutter, the machine can use for flat, bevel, angle, groove and edge processing. The machine can also be milling gears, reamers, spiral grooves, cams and drums instal with indexing accessories and others, which is widely used in machining industries.
Parameters
Working range
Unit
- X/Y/Z axis travel
- 1020/300/410 mm
- Distance from spindle nose to table surface
- 60-460 mm
- Distance from spindle center to vertical guideway
- 380 mm
- Distance from table center to vertical guideway
- 235-535 mm
WorktableUnit
- Worktable size
- 360x1600mm
- T slots
- 3-18*80mm
- Max. load bearing of worktable
- 500kg
Spindle
Unit
- Spindle hole taper
- 7:24 No.50
- Spindle power
- 7.5KW
- Max. spindle speed
- 1500rpm
Feed
Unit
- Rapid feed speed
- 2250/2250/844mm/min
- Feed speed range
- 15-750/15-750/5.7-280mm/min
Machine
Unit
- Machine dimension
- 2307*2067*2096mm
- Machine weight
- 3370kg
